Benchmark: Single-Threaded Reading Performance of Compressed MERA Files

This guide shows how to benchmark the reading speed of compressed MERA files using Mera.jl, and why the MERA format is much faster to read than the original RAMSES files.

Why MERA files read faster. A MERA .jld2 file stores the already-parsed data table. Reading it (loaddata) just deserializes and decompresses that table. Reading the original RAMSES output instead re-parses every per-CPU Fortran binary file (often hundreds to thousands of files per component) and rebuilds the AMR structure from scratch on every read. Skipping that parse work is the dominant effect — so the MERA read advantage holds even on a fast local SSD, and grows further on servers with networked/parallel filesystems where opening the many RAMSES files adds latency.

Two robust benefits (measured, fair comparison — same data both sides):

• Much faster reads. Loading hydro + particles + gravity of one output: ~2 s from the MERA file vs ~86 s from RAMSES (single thread) — roughly 30–40× faster — even on a local NVMe SSD, and even versus multi-threaded RAMSES reading (~71 s, still ~30×). See the table below.
• Smaller on disk. A complete MERA file is ~62% smaller / ~2.6× than the RAMSES output it was made from.
• Lower peak memory. MERA-file reading peaked ~35% below single-threaded RAMSES in the reference run (8.0 vs 13.0 GB), avoiding the per-file parse buffers.

Overview

Mera.jl enables efficient reading of RAMSES simulation files, which are often compressed to reduce storage requirements. This test benchmarks the reading of hydro, particle, and gravity components from a specified output, measuring timings and reporting average speeds.

Prerequisites

Before running the test, ensure you have:

• Julia ≥ 1.10 (recommended)
• Mera.jl installed in your Julia environment
• MERA files: Access to compressed simulation outputs (e.g., output_00250.jld2)
• Hardware: Sufficient memory and storage (decompression may require extra RAM)

Installation

Activate your Julia environment and install Mera.jl:

using Pkg
Pkg.activate(".")
Pkg.add("Mera")

Benchmark script: run_test.jl

The benchmark script loads simulation metadata, reads each component (:hydro, :particles, :gravity) once, measures the time taken, and reports reading speed in MB/s.

Download it from the repository:

curl -L -O https://github.com/ManuelBehrendt/Mera.jl/raw/master/src/benchmarks/JLD2_reading/downloads/run_test.jl

(or browse it here).

Edit the simulation path and output number near the top of run_test.jl, then run it single-threaded with your chosen Julia version:

julia +1.12 -t 1 run_test.jl

Saving Output for Later Analysis

To save the screen output of your benchmark run for later review, pipe the output to a file in your benchmark folder. For example, on macOS or Linux:

If you use juliaup to manage Julia versions, you can specify the Julia version for the run. For example, to use Julia 1.10:

julia +1.11 -t 1 run_test.jl | tee benchmarks/benchmark_$(date +%Y-%m-%d).log

This will run the script with Julia 1.10 (or your chosen version), using a single thread, and store the output in a file named with today's date (e.g., benchmark_2025-07-26.log) inside the benchmarks folder. Adjust the folder name and Julia version as needed.

Key Script Components

• Metadata Loading: Uses infodata to retrieve simulation details without verbose output.
• Component Reading: Calls loaddata for :hydro, :particles, and :gravity in sequence, timing each operation.
• Speed Calculation: Computes MB/s based on estimated file sizes.
• Output: Prints timings and speeds for each component, plus a total summary.

Measured results

All numbers below are a fair, like-for-like comparison: the MERA file and the RAMSES output contain the same components (hydro + particles + gravity), and both load the same 4.05 GB into memory. Reference machine: Apple M2 Pro, 12 cores, 32 GB RAM, macOS 26.2, Julia 1.12.3; dataset mw_L10 output 300 (ncpu = 640 → ~640 files per component); local NVMe SSD.

Read speed

Reading the MERA file is ~30–40× faster than RAMSES (warm: ~2.4 s vs ~86 s single-thread ≈ 36×; vs ~71 s with 8 threads ≈ 30×) — on a fast local SSD (run-to-run variance ~30–43×). The gap is intrinsic: loaddata deserializes a ready-made table, whereas RAMSES reading re-parses ~1,900 Fortran files and rebuilds the AMR tree every time. On networked/parallel server filesystems the gap widens further (per-file open latency adds to the RAMSES side — see Server IO and Parallel RAMSES reading).

Storage reduction

A complete MERA file (all three components) vs the RAMSES output it was made from:

Reduction = 100 × (1 − MERA/RAMSES) (LZ4-compressed). Holds independently of hardware.

Peak memory

MERA-file reading peaked at 8.0 GB vs 13.0 GB for single-threaded RAMSES (~35% lower) for the same in-memory result — RAMSES reading needs additional intermediate per-file parse buffers.

Summary for choosing the MERA format: a large win for storage (~62% / 2.6× here) and for read speed — ~30–40× faster than RAMSES even on a fast local NVMe SSD, growing further on servers/networked or slow storage with many files — plus ~35% lower peak memory. Reproduce the table above on your own target storage with the script in this guide.
