Multi-Threading & Garbage Collection in Mera

Complete guide for high-performance RAMSES simulation analysis with Julia 1.10+

High-performance parallel computing with MERA.jl: leveraging multi-core processors for accelerated astrophysical data analysis

Main Takeaways

• Julia's composable threading and parallel GC for multi-GB AMR loads, projections, and VTK exports
• Concurrent threading at multiple levels can saturate I/O and memory—use Mera's max_threads keyword to control internal concurrency
• Benchmark each threaded function to find your server's optimal thread counts
• Examples to transform your existing code into parallel workflows with minimal changes

Quick Start Guide

For Complete Beginners

New to Julia threading AND Mera? Start here:

1. Setup: Start Julia with julia -t auto (uses all available CPU cores)
   • HPC users: Check core count first with julia -e "println(Sys.CPU_THREADS)", then use explicit count
2. Verify: Run Section 4.1 setup verification
3. Learn basics: Read Sections 1-3 (threading concepts, memory, resource contention)
4. Practice fundamentals: Try Section 6.0 practice exercises
5. Understand patterns: Study Section 6 (outer-loop vs inner-kernel vs mixed)
6. Apply: Use Section 12 complete examples on your data

For Julia Users New to Mera Threading

Know Julia threading but new to Mera? Follow this path:

1. Mera specifics: Jump to Section 5 (function support and max_threads)
2. Practice: Try Section 6.0 exercises to see Mera patterns
3. Choose pattern: Section 6 for your use case
4. Transform code: Section 9 to adapt existing workflows
5. Optimize: Section 10 for performance tuning

For Experienced Users

Already familiar with both? Quick navigation:

• Reference: Section 5 (function support), Quick Reference below
• Patterns: Section 6 (core), Section 7 (advanced)
• Examples: Section 9 (transformations), Section 12 (production)
• Troubleshooting: Section 10 (performance), Section 11 (best practices)

By Specific Goal

What do you want to achieve?

• Process multiple snapshots/parameters → Section 6.1 (Outer-Loop Pattern)
• Analyze single large dataset → Section 6.2 (Inner-Kernel Pattern)
• Build complex multi-stage workflows → Section 6.3 (Mixed) + Section 7 (Advanced)
• Fix memory/GC issues → Section 2 (Memory/GC) + Section 11.2 (Troubleshooting)
• Improve performance → Section 10 (Benchmarking) + Section 11.1 (Best Practices)
• Make existing code threaded → Section 9 (Tutorial Transformations)
• Thread safety problems → Section 8 (Thread-Safe Programming)

Quick Reference

Essential Commands

# Start Julia with threading
julia -t auto  # Uses all available CPU cores

# Check threading status
using Base.Threads
nthreads()  # Should be > 1

# Basic verification test
@threads for i in 1:nthreads()
    println("Thread $(threadid()) working")
end

Core Patterns

Function Threading Support

Thread-Safe Data Collection

# ✅ Safe: Pre-allocated arrays
results = Vector{Float64}(undef, n)
@threads for i in 1:n
    results[i] = compute(i)  # Each thread → different index
end

# ✅ Safe: Atomic operations
total = Atomic{Float64}(0.0)
@threads for i in 1:n
    atomic_add!(total, compute(i))
end

# ❌ Unsafe: Race conditions
total = 0.0
@threads for i in 1:n
    global total += compute(i)  # Multiple threads → same variable
end

Common Gotchas

• Resource contention: Use max_threads to optimize I/O and memory bandwidth usage
• Memory allocation: High GC time (>15%) → pre-allocate arrays
• Thread verification: Always check nthreads() > 1 before threading
• Error handling: Wrap threaded code in try-catch blocks

Performance Rules of Thumb

• I/O bound: More threads (4-8) help
• CPU bound: Match physical cores
• Memory bound: Fewer threads (2-4)
• Network storage: Even fewer threads, benefit from compression

Threading Decision Framework

When TO Use Threading

✅ Perfect for Threading:

• Processing multiple snapshots/parameters in parallel
• Analyzing single large datasets with multiple variables
• Time series analysis across many simulation outputs
• Parameter sweeps with independent calculations
• I/O-heavy operations (loading, exporting data)

📊 Threading Decision Tree:

Do you have multiple independent tasks?
├─ YES → Use Outer-Loop Pattern (@threads + max_threads=1)
│   └─ Examples: Multiple snapshots, parameter studies
│
└─ NO → Is your dataset large with multiple variables?
    ├─ YES → Use Inner-Kernel Pattern (full threading)
    │   └─ Examples: Multi-variable projections, complex analysis
    │
    └─ NO → Consider Mixed Pattern or stay single-threaded
        └─ Examples: Small datasets, simple calculations

When NOT to Use Threading

❌ Threading Won't Help:

• Single small calculations - Threading overhead > benefit
• Memory-starved systems - Will make GC worse
• Single snapshot + single variable - Already optimized
• Network bottlenecked I/O - May actually slow things down
• Thread-unsafe external libraries - Will cause crashes

⚖️ Cost-Benefit Analysis:

Threading Overhead vs. Parallel Benefit

HIGH BENEFIT:                    LOW/NEGATIVE BENEFIT:
▓▓▓▓▓▓▓▓░░ Many snapshots        ░░▓▓░░░░░░ Single calculation
▓▓▓▓▓▓▓░░░ Large datasets        ░▓▓▓░░░░░░ Small arrays
▓▓▓▓▓▓░░░░ I/O bound tasks       ░░▓▓▓▓░░░░ CPU saturated
▓▓▓▓▓░░░░░ Multiple variables    ░░░▓▓▓▓▓░░ Memory limited

🧠 Quick Decision Checklist:

1. Multiple independent items? → Threading likely beneficial
2. Single item but large/complex? → Inner parallelism may help
3. Small, simple calculation? → Skip threading
4. Unsure? → Benchmark both approaches (see Section 10)

Visual Threading Concepts

Thread Pool Allocation:

Available Threads: [T1] [T2] [T3] [T4] [T5] [T6] [T7] [T8]

Outer-Loop Pattern:
Snapshot 1 → [T1] gethydro(max_threads=1)
Snapshot 2 → [T2] gethydro(max_threads=1)
Snapshot 3 → [T3] gethydro(max_threads=1)
Snapshot 4 → [T4] gethydro(max_threads=1)

Inner-Kernel Pattern:
Variable :rho → [T1] [T2] projection
Variable :T   → [T3] [T4] projection
Variable :vx  → [T5] [T6] projection
Variable :vy  → [T7] [T8] projection

Resource Contention Visualization:

Without max_threads (Bad):
Thread 1: [████████████████] I/O + CPU intensive
Thread 2: [████████████████] I/O + CPU intensive  ← Bandwidth fight
Thread 3: [████████████████] I/O + CPU intensive
Thread 4: [████████████████] I/O + CPU intensive

With max_threads=1 (Good):
Thread 1: [████████████████] Full I/O bandwidth
Thread 2: [────────────────] Waiting
Thread 3: [────────────────] Waiting
Thread 4: [────────────────] Waiting

Self-Assessment Checkpoints

Checkpoint 1: Threading Readiness ✓

Before proceeding, verify:

• [ ] Julia started with -t auto (uses all CPU cores) or -t N (explicit count)
• [ ] On HPC clusters: Check Sys.CPU_THREADS and use explicit counts instead of auto
• [ ] Threads.nthreads() > 1 returns true
• [ ] You understand the difference between outer-loop and inner-kernel patterns
• [ ] You can identify whether your task is I/O, CPU, or memory bound

Test your setup:

using Base.Threads
println("Threads available: $(nthreads())")
@threads for i in 1:4
    println("Thread $(threadid()) processing task $i")
    sleep(0.1)
end

Checkpoint 2: Pattern Selection ✓

Can you choose the right pattern?

Scenario A: Analyze snapshots 100, 200, 300, 400 for total mass

• Your choice: Outer-loop / Inner-kernel / Mixed?
• Correct: Outer-loop (@threads over snapshots, max_threads=1)

Scenario B: Create density, temperature, and velocity projections from one large dataset

• Your choice: Outer-loop / Inner-kernel / Mixed?
• Correct: Inner-kernel (let projection() handle multiple variables)

Scenario C: Export VTK files for 10 different spatial regions from the same snapshot

• Your choice: Outer-loop / Inner-kernel / Mixed?
• Correct: Mixed or Outer-loop (depends on region size and memory)

Try This: Hands-On Threading Exercises

Exercise 1: Basic Threading Test

using Base.Threads

# Simulate Mera workflow timing
function mock_mera_analysis(snapshot_id)
    thread_id = threadid()
    println("Thread $thread_id starting snapshot $snapshot_id")

    # Simulate getinfo (fast)
    sleep(0.01)

    # Simulate gethydro (slower)
    sleep(0.2)

    # Simulate projection (moderate)
    sleep(0.1)

    println("Thread $thread_id finished snapshot $snapshot_id")
    return (snapshot=snapshot_id, thread=thread_id, total_mass=rand(1e10:1e12))
end

# Test threaded vs serial
snapshots = 1:8

println("=== SERIAL VERSION ===")
@time serial_results = [mock_mera_analysis(s) for s in snapshots]

println("\n=== THREADED VERSION ===")
results = Vector{Any}(undef, length(snapshots))
@time @threads for i in eachindex(snapshots)
    results[i] = mock_mera_analysis(snapshots[i])
end

println("Speedup: $(length(serial_results)*0.31 / (time_threaded))x")

Expected behavior: You should see multiple thread IDs working simultaneously, and significant speedup.

Exercise 2: Resource Contention Simulation

# Simulate resource contention
function io_heavy_task(task_id, max_threads)
    println("Task $task_id using max_threads=$max_threads")

    # Simulate heavy I/O (like reading large files)
    if max_threads == 1
        sleep(0.3)  # Serial I/O - efficient
    else
        sleep(0.5)  # Parallel I/O - contention overhead
    end

    return "Task $task_id completed"
end

# Compare contention patterns
println("=== HIGH CONTENTION (max_threads=auto) ===")
@time @threads for i in 1:8
    io_heavy_task(i, Threads.nthreads())
end

println("\n=== LOW CONTENTION (max_threads=1) ===")
@time @threads for i in 1:8
    io_heavy_task(i, 1)
end

Learning goal: Understand why max_threads=1 can sometimes be faster.

Exercise 3: Thread Safety Practice

using Base.Threads

# UNSAFE version - race condition
function unsafe_accumulation(n)
    total = 0.0
    @threads for i in 1:n
        total += i  # DANGER: Multiple threads writing same variable
    end
    return total
end

# SAFE version - atomic operations
function safe_accumulation(n)
    total = Atomic{Float64}(0.0)
    @threads for i in 1:n
        atomic_add!(total, i)
    end
    return total[]
end

# SAFE version - pre-allocated array
function safe_array_accumulation(n)
    results = Vector{Float64}(undef, n)
    @threads for i in 1:n
        results[i] = i  # Safe: each thread writes different index
    end
    return sum(results)
end

# Test all approaches
n = 10000
expected = sum(1:n)

println("Expected result: $expected")
println("Unsafe result: $(unsafe_accumulation(n)) (may be wrong!)")
println("Safe atomic result: $(safe_accumulation(n))")
println("Safe array result: $(safe_array_accumulation(n))")

Learning goal: See race conditions in action and learn safe alternatives.

1 Introduction to Multi-Threading & GC

1.1 Why Multi-Threading Matters for Scientists

Julia's native multi-threading lets you utilize your available cores within pure Julia code—no external libraries, MPI, or complex setup required.

For Mera users, this means the following functions are already internally parallelized:

• AMR data loading (gethydro/getgravity) reads levels concurrently
• Particle streaming (getparticles) processes files in parallel
• Projection creation (projection) spawns one thread per variable for hydro data
• VTK export (export_vtk) writes chunks simultaneously

1.2 Julia's Unique Advantage: Composable Threading

Unlike languages that retrofit parallelism, Julia was designed with composable threading from the ground up. When one multi-threaded function calls another multi-threaded function, Julia's scheduler coordinates all threads globally without oversubscribing resources.

This architectural advantage is crucial for scientific computing where you might:

• Process multiple simulation snapshots simultaneously
• Run different analysis algorithms in parallel
• Export visualization data while computing results
• Perform parameter sweeps with thousands of iterations

1.3 Parallel Garbage Collection

Julia 1.10+ introduces parallel garbage collection—the GC's mark phase runs on multiple threads, dramatically reducing pause times for allocation-heavy applications. This is especially important when processing large RAMSES datasets that create many temporary objects.

2 Memory Management & Garbage Collection

2.1 Stack vs Heap Memory

Understanding Julia's memory model helps optimize threaded code:

Memory Architecture Visualization:

┌─────────── PROCESS MEMORY SPACE ───────────┐
│                                            │
│  ┌─ STACK (Thread 1) ──┐  ┌─ STACK (Thread 2) ──┐
│  │ function_call()     │  │ function_call()     │
│  │ local_vars = 5.0    │  │ local_vars = 3.2    │
│  │ return_address      │  │ return_address      │
│  │ ▲ GROWS UP          │  │ ▲ GROWS UP          │
│  └─────────────────────┘  └─────────────────────┘
│                                                  │
│  ┌──────── SHARED HEAP (All Threads) ──────────┐
│  │  [Array 1] [Dict 1] [Large Matrix]         │
│  │  [Array 2] [Struct] [String Data]          │
│  │  ┌─ Garbage Collection ─┐                   │
│  │  │ Mark → Sweep → Free  │                   │
│  │  └─────────────────────┘                   │
│  └─────────────────────────────────────────────┘
└────────────────────────────────────────────────┘

Stack Memory

• Fast, linear LIFO (Last-In-First-Out) structure
• Stores local variables, function parameters, return addresses
• Fixed size, known at compile time
• Automatically freed when function returns
• Thread-safe: Each thread has its own stack

Heap Memory

• Flexible region for dynamic objects
• Arrays, dictionaries, complex data structures
• Size determined at runtime
• Managed by garbage collector
• Shared: All threads access the same heap

function memory_example()
    x = 5.0                    # Stack: small, fixed-size local
    arr = rand(10^6)           # Heap: large, dynamic array
    return sum(arr)            # Stack freed automatically, arr marked for GC
end

2.2 Julia's Garbage Collector Explained

Julia implements a generational, mark-and-sweep collector:

Garbage Collection Visualization:

BEFORE GC:                    MARK PHASE:                    SWEEP PHASE:
┌─ HEAP ─────────┐           ┌─ HEAP ─────────┐           ┌─ HEAP ─────────┐
│ [A]━━━━━━━[B]  │  Thread 1 │ [A]✓━━━━━━━[B]✓ │  Thread 1 │ [A]     [B]    │
│  ▲         ▲   │    ┃      │  ▲         ▲   │    ┃      │  ▲       ▲     │
│  ┃         ┗━━━│━━━━┃━━━━━▶│  ┣MARK     ┗━━━│━━━━┣━━━━▶│  ┗━━━━━━━┛      │
│ ROOT      [C]  │  Thread 2 │ ROOT✓    [C]✗  │  Thread 2 │ ROOT      [FREE] │
│            ▲   │    ┃      │            ▲   │    ┃      │           [FREE] │
│           [D]━━│━━━━┗━━━━━▶│           [D]✗━━│━━━━┗━━━━▶│           [FREE] │
└────────────────┘           └────────────────┘           └────────────────┘
   Unreachable objects        ✓=Reachable ✗=Unreachable    Freed memory

Mark Phase: Starting from "roots" (global variables, local variables on call stacks), the GC traces all reachable objects. Julia 1.10+ parallelizes this phase across multiple threads.

Sweep Phase: Unreachable objects are deallocated and memory returned to the system.

Generational Strategy: Most objects die young. The GC focuses on recently allocated objects, which are statistically more likely to be garbage.

Multi-Threaded GC Benefits:

SINGLE-THREADED GC:          PARALLEL GC (Julia 1.10+):

GC Thread: [████████████]    GC Thread 1: [███████]
Program:   [─wait─.......... Program:     [███████] ← Less waiting
                            GC Thread 2: [███████]
Total:     [████████████──]  Total:       [████████] ← Faster overall
           ↑ 12 time units                ↑ 8 time units

2.3 Monitoring GC Performance

Use @time to monitor GC impact:

@time result = analyze_large_dataset(data)
# Output: 2.345 seconds (1.23 M allocations: 456.7 MiB, 15.2% gc time)

The 15.2% gc time indicates that over 15% of execution time was spent in garbage collection. Values above 10-20% suggest optimization opportunities.

2.4 GC Optimization Strategies

Minimize Allocations

# BAD: Creates temporary arrays
function inefficient_physics(positions, velocities, masses)
    kinetic = 0.5 .* masses .* (velocities .^ 2)  # Temporary array
    potential = compute_potential(positions)       # Another temporary
    return sum(kinetic) + sum(potential)          # More temporaries
end

# GOOD: Single pass, no allocations
# No intermediate arrays: every arithmetic operation writes straight into the scalar total
function efficient_physics(positions, velocities, masses)
    total_energy = 0.0
    for i in eachindex(positions)
        total_energy += 0.5 * masses[i] * velocities[i]^2
        total_energy += compute_potential_at(positions[i])
    end
    return total_energy
end

-> Allocation-Free Variants That Keep Broadcasting Style

# 1. Fuse Everything and Stream to a Pre-Allocated Vector
# The dotted assignment out .= … fuses all elementwise operations and writes directly into out, so no extra storage is needed
function energy_broadcast!(out, pos, vel, m)
    @. out = 0.5*m*vel^2 + compute_potential_at(pos)
    return sum(out)
end

# 2. Map-Reduce Without Intermediates
energy_mapreduce(pos, vel, m) = mapreduce(i -> 0.5*m[i]*vel[i]^2 + compute_potential_at(pos[i]), +, eachindex(pos))

Preallocate Arrays

# BAD: Growing arrays cause repeated reallocations
function collect_slow(n)
    results = Float64[]  # Starts empty
    for i in 1:n
        push!(results, expensive_calc(i))  # Repeated reallocations
    end
    return results
end

# GOOD: Allocate once
function collect_fast(n)
    results = Vector{Float64}(undef, n)  # Single allocation
    for i in 1:n
        results[i] = expensive_calc(i)
    end
    return results
end

Use In-Place Operations

# BAD: Creates new arrays
function update_slow(state, forces, dt)
    new_vel = state.velocities + forces .* dt      # New array
    new_pos = state.positions + new_vel .* dt      # Another new array
    return SimulationState(new_pos, new_vel)
end

# GOOD: In-place updates
function update_fast!(state, forces, dt)
    @. state.velocities += forces * dt             # In-place
    @. state.positions += state.velocities * dt    # In-place
    return state
end

3 Understanding Resource Contention & max_threads

Note: With Julia-only threading you typically don't oversubscribe OS threads; the main risk in nested parallel workflows is resource contention (I/O, memory bandwidth, cache/NUMA).

3.1 What Is Oversubscription?

Oversubscription occurs when you have more runnable threads than physical CPU cores. The operating system must constantly switch between threads, leading to:

• Context switch overhead: Saving and restoring thread state takes time
• Cache thrashing: Threads compete for the same CPU caches, reducing efficiency
• Memory bandwidth contention: Multiple threads saturate memory channels
• False sharing: Different threads modify variables on the same cache line

3.2 Why Resource Contention Happens with Mera

Great question! Julia's composable threading does work excellently, and since Mera uses only Julia's native threading capabilities, the scheduler should coordinate everything properly. However, there are still practical scenarios where controlling threading improves performance:

1. Resource Contention vs Thread Management Julia prevents creating too many OS threads, but it can't prevent resource bottlenecks:

# Julia manages this perfectly at the thread level:
@threads for snapshot in snapshots              # 8 tasks
    gas = gethydro(info; lmax=10)               # Each uses all threads internally
    projection(gas, [:rho, :T, :vx, :vy])      # More internal threading
end
# But all 8 processes hit storage/memory simultaneously

2. Memory Bandwidth Saturation

System Resource Bottleneck Visualization:

┌─────── CPU CORES (8 available) ────────┐
│ [Core1] [Core2] [Core3] [Core4]        │
│ [Core5] [Core6] [Core7] [Core8]        │  ✓ Usually not the bottleneck
└─────────────────────────────────────────┘
                    │
                    ▼
┌──────── MEMORY BANDWIDTH ──────────────┐
│ RAM: 64 GB                             │
│ Bandwidth: 25.6 GB/s ←── BOTTLENECK   │  ⚠️ Often saturated first!
│ 8 threads × 2GB/s = 16GB/s (63% util) │
└─────────────────────────────────────────┘
                    │
                    ▼
┌─────────── STORAGE I/O ────────────────┐
│ SSD: 500 MB/s                          │
│ Network Storage: 100 MB/s ←── BOTTLENECK│  ⚠️ Worst with many threads
│ 8 concurrent reads = 800 MB/s demand   │
└─────────────────────────────────────────┘

Multiple threads reading large AMR datasets can saturate:

• Memory bandwidth: 8 threads × 2GB/thread = 16GB/s (may exceed RAM bandwidth)
• Storage I/O: Network filesystems often perform better with fewer concurrent readers
• CPU caches: Context switching between many active memory-intensive tasks

3. NUMA Effects on Multi-Socket Systems

NUMA Architecture Visualization:

┌─── SOCKET 0 ────┐    ┌─── SOCKET 1 ────┐
│ [CPU0-3] MEM0   │    │ [CPU4-7] MEM1   │
│      ▲          │    │      ▲          │
│      │ FAST     │    │      │ FAST     │
└──────┼──────────┘    └──────┼──────────┘
       │                      │
       └──── SLOW LINK ───────┘
              (QPI/UPI)

OPTIMAL:              SUBOPTIMAL:
Thread1@CPU0 → MEM0   Thread1@CPU0 → MEM1  ← Cross-socket penalty
Thread2@CPU1 → MEM0   Thread2@CPU4 → MEM0  ← Cross-socket penalty

On large servers with multiple CPU sockets:

• Memory access is faster when threads stay on the same NUMA node
• Too many concurrent threads can cause cross-socket memory traffic

4. Julia's Fair Scheduling vs Performance Optimization Julia's scheduler is fair but not necessarily optimal for scientific workloads:

• Equal resource sharing among all tasks
• May not account for the specific I/O patterns of large file reads

3.3 The max_threads Solution

Mera functions accept a max_threads::Integer keyword to provide explicit control over resource usage:

# SOLUTION: Optimize resource usage rather than prevent contention
@threads for snapshot in snapshots              # 8 outer threads (Julia tasks)
    gas = gethydro(info; lmax=10, max_threads=2)    # Limit concurrent I/O
    projection(gas, [:rho, :T]; max_threads=2)      # Control memory pressure
end
# Result: Better memory/I/O utilization patterns

Why Use max_threads With Julia's Smart Scheduling?

1. I/O Optimization: Network storage often performs better with fewer concurrent readers
2. Memory Bandwidth: Large datasets benefit from controlled memory access patterns
3. Cache Efficiency: Fewer active threads = better CPU cache utilization
4. NUMA Awareness: Better memory locality on multi-socket systems
5. Performance Tuning: Precise optimization for your specific hardware and data sizes

max_threads Options:

• max_threads = Threads.nthreads() (default): Use all available threads
• max_threads = 1: Run completely serially
• max_threads = N: Optimize for N concurrent operations

The Real Benefit: max_threads isn't about preventing Julia from breaking - it's about optimizing for the physical realities of large scientific datasets, storage systems, and memory hierarchies.

4 Setting Up Julia for Threading

4.1 Quick Setup Verification

Step 1: Check Your Current Threading Status

Run this to see your current configuration:

using Base.Threads

println("Julia Threading Environment:")
println("=" ^ 50)
println("Number of threads available: ", nthreads())
println("Thread IDs: ", 1:nthreads())
println("Current thread: ", threadid())

# Check if we have multiple threads
if nthreads() == 1
    println("\n⚠️  WARNING: Running with only 1 thread!")
    println("To enable multithreading:")
    println("1. Exit Julia")
    println("2. Restart with: julia -t auto (uses all available CPU cores)")
    println("3. Or use: julia -t 4 (for exactly 4 threads)")
    println("4. Most benefits of this tutorial require multiple threads")
else
    println("\n✅ SUCCESS: Multi-threading is available!")
    println("You have ", nthreads(), " threads ready for parallel processing")
end

Step 2: Basic Threading Test

Verify threading works by running this simple test:

# Basic threading demonstration
println("\nBasic Threading Test:")
println("Available threads: ", nthreads())

# Simple parallel task - each thread identifies itself
@threads for i in 1:nthreads()
    println("Thread ", threadid(), " processing task ", i)
    sleep(0.1)  # Simulate work
end

println("✅ Basic threading test completed!")
println("Note: If you see output from multiple thread IDs, threading is working correctly.")

4.2 Important Notes on Thread Count Selection

# Check total CPU cores
julia -e "println(\"Total CPU cores: \", Sys.CPU_THREADS)"

# Check NUMA topology (if available)
lscpu | grep -E "CPU\(s\)|NUMA"

# Use explicit counts based on your allocation
julia -t 16  # For 16-core allocation
julia -t 32  # For 32-core allocation

4.3 Basic Thread Configuration

By default, Julia starts with a single thread:

julia> Threads.nthreads()
1

Enable multi-threading at startup:

# Command line argument (recommended)
julia --threads=8                    # 8 threads total
julia --threads=auto                 # Uses all available CPU cores
julia -t 4                          # Short form (explicit count)

# Environment variable method
export JULIA_NUM_THREADS=8
julia

4.4 Advanced Configuration (Julia 1.10+)

Julia 1.10+ supports two thread pools and parallel GC:

# 8 compute threads, 2 interactive threads, 4 GC threads
julia --threads=8,2 --gcthreads=4

# Auto-configure everything (recommended for beginners)
julia --threads=auto --gcthreads=auto  # Uses all available CPU cores

Thread Pools:

• :default pool: Compute-intensive tasks
• :interactive pool: UI and responsive operations (keeps REPL responsive)

Verification:

using Base.Threads

println("Compute threads: ", nthreads(:default))
println("Interactive threads: ", nthreads(:interactive))
println("Current thread: ", threadid())
println("Current pool: ", threadpool())
# Note: GC thread count available in Julia 1.10+ with specific functions

# Optimize BLAS for linear algebra
using LinearAlgebra
BLAS.set_num_threads(min(4, nthreads()))
println("BLAS threads: ", BLAS.get_num_threads())

4.5 Recommended Configurations

For laptops/workstations (4-8 cores):

julia --threads=auto --gcthreads=auto  # Uses all available CPU cores

For smaller servers (16+ cores):

julia --threads=12,2 --gcthreads=6

For larger servers (32+ cores):

julia --threads=32,4 --gcthreads=16

#SBATCH --cpus-per-task=16
julia --threads=16,2 --gcthreads=8

#SBATCH --cpus-per-task=32
julia --threads=32,4 --gcthreads=16

echo "Allocated CPUs: $SLURM_CPUS_PER_TASK"
echo "Total node CPUs: $(nproc)"
julia -e "println(\"Detected CPUs: \", Sys.CPU_THREADS)"

5 Mera's Internally Threaded Functions

5.1 Overview of Threaded Functions

Mera Function Threading Architecture:

┌─ MERA FUNCTION CALL ──────────────────────────────────────────┐
│                                                               │
│  gethydro(info; lmax=10, max_threads=4)                      │
│                     ↓                                         │
│  ┌─ PARALLEL FILE LOADING ─┐   ┌─ PARALLEL TABLE CREATION ─┐  │
│  │ Thread 1: amr_001.out01 │   │ Thread 1: :rho column    │  │
│  │ Thread 2: amr_002.out01 │   │ Thread 2: :vx column     │  │
│  │ Thread 3: amr_003.out01 │   │ Thread 3: :vy column     │  │
│  │ Thread 4: amr_004.out01 │   │ Thread 4: :vz column     │  │
│  └─────────────────────────┘   └───────────────────────────┘  │
│                                                               │
│  projection(gas, [:rho, :T, :vx]; max_threads=3)             │
│                     ↓                                         │
│  ┌─ PARALLEL VARIABLE PROCESSING ──────────────────────────┐  │
│  │ Thread 1: Process :rho → density map                   │  │
│  │ Thread 2: Process :T   → temperature map               │  │
│  │ Thread 3: Process :vx  → velocity map                  │  │
│  └─────────────────────────────────────────────────────────┘  │
└───────────────────────────────────────────────────────────────┘

6 Core Threading Patterns

6.0 Quick Practice: Threading Fundamentals

Before diving into Mera-specific patterns, let's practice basic threading concepts:

using Base.Threads

# Practice 1: Simple parallel simulation
function simulate_mera_workflow(snapshot_name)
    thread_id = threadid()
    println("Thread $thread_id processing $snapshot_name")

    # Simulate Mera operations with realistic timing
    sleep(0.05)  # getinfo() - fast
    sleep(0.2)   # gethydro() - slower
    sleep(0.1)   # projection() - moderate

    return "Processed $snapshot_name on thread $thread_id"
end

# Test external threading pattern
println("🧪 Testing External Threading Pattern:")
snapshots = ["snap_001", "snap_002", "snap_003", "snap_004"]
results = Vector{String}(undef, length(snapshots))

start_time = time()
@threads for i in eachindex(snapshots)
    results[i] = simulate_mera_workflow(snapshots[i])
end
elapsed = round(time() - start_time, digits=2)

println("⏱️  Completed in $(elapsed)s")
for result in results
    println("  ", result)
end

Expected Output: You should see different thread IDs processing different snapshots simultaneously.

6.1 Pattern 1: Outer-Loop Parallelism

When to use: Processing multiple independent snapshots, parameter combinations, or spatial regions.

Strategy: Parallelize the outer loop, disable internal threading.

using Mera, Base.Threads

# Process multiple snapshots in parallel
snapshots = 100:25:400
results = Vector{NamedTuple}(undef, length(snapshots))

@threads for i in axes(snapshots, 1) # or use : @threads for i in 1:length(snapshots)
    snapshot = snapshots[i]
    info = getinfo(snapshot, SIMPATH)

    # Disable internal threading to reduce contention
    gas = gethydro(info; lmax=10, max_threads=1)
    particles = getparticles(info; max_threads=1)

    # Perform analysis
    gas_mass = msum(gas, :Msol)
    stellar_mass = msum(particles, :Msol)
    time_myr = gettime(info, :Myr)

    results[i] = (
        snapshot = snapshot,
        time_myr = time_myr,
        gas_mass = gas_mass,
        stellar_mass = stellar_mass,
        total_mass = gas_mass + stellar_mass
    )
end

6.2 Pattern 2: Inner-Kernel Parallelism

When to use: Processing a single large dataset with multiple analysis types.

Strategy: Let Mera's internal threading handle parallelism.

using Mera

# Load single large dataset with full parallelization
info = getinfo(400, SIMPATH)
gas = gethydro(info; lmax=12)  # Uses all available threads internally

# Create multiple projections - one thread per variable
# Each variable gets its own thread automatically
vars = [:rho, :p, :T, :vx, :vy, :vz]
p = projection(gas, vars; lmax=11) # or use: projections = projection(gas, vars; pxsize=[100., :pc])

6.3 Pattern 3: Mixed Parallelism

When to use: Balancing multiple tasks with controlled resource allocation.

Strategy: Combine outer parallelism with capped inner threading.

using Mera, Base.Threads

function analyze_simulation_comprehensive(info)
    # Allocate threads carefully across tasks
    tasks = []

    # Task 1: Hydro analysis (3 threads)
    push!(tasks, @spawn begin
        gas = gethydro(info; lmax=10, max_threads=3)
        density_proj = projection(gas, :rho; lmax=9, max_threads=2)
        (type="hydro", result=density_proj)
    end)

    # Task 2: Particle analysis (3 threads)
    push!(tasks, @spawn begin
        particles = getparticles(info; max_threads=3)
        stellar_mass = msum(particles, :Msol)
        (type="particles", result=stellar_mass)
    end)

    # Task 3: Export (2 threads)
    # here: reading data again for demonstrating purposes only
    push!(tasks, @spawn begin
        gas = gethydro(info; lmax=8, max_threads=2)
        export_vtk(gas, "output_$(info.output)";
                  scalars=[:rho, :p])
        (type="export", result="completed")
    end)

    return fetch.(tasks)  # Wait for all tasks to complete
end

7 Advanced Threading Patterns

7.1 Producer-Consumer Pipeline

Use case: Streaming data processing with multiple stages.

using Mera, Base.Threads

function parallel_analysis_pipeline(snapshot_range, SIMPATH, analysis_functions)
    # Stage 1: Data loading (producer)
    data_channel = Channel{NamedTuple}(50)  # Buffered channel

    @spawn begin  # Producer task
        @sync for snapshot in snapshot_range
            @spawn begin
                try
                    info = getinfo(snapshot, SIMPATH)
                    gas = gethydro(info; lmax=10, max_threads=1)
                    put!(data_channel, (snapshot=snapshot, gas=gas, info=info))
                catch e
                    @warn "Failed to load snapshot $snapshot: $e"
                end
            end
        end
        close(data_channel)
    end

    # Stage 2: Analysis processing (consumers)
    results_channel = Channel{NamedTuple}(25)

    @spawn begin
        @sync for _ in 1:nthreads()  # Spawn consumer tasks
            @spawn begin
                for data_item in data_channel
                    try
                        # Apply all analysis functions
                        analysis_results = Dict()
                        for (func_name, func) in analysis_functions
                            analysis_results[func_name] = func(data_item.gas)
                        end

                        put!(results_channel, (
                            snapshot = data_item.snapshot,
                            time_myr = gettime(data_item.info, :Myr),
                            analyses = analysis_results
                        ))
                    catch e
                        @warn "Analysis failed for snapshot $(data_item.snapshot): $e"
                    end
                end
            end
        end
        close(results_channel)
    end

    # Collect results
    return collect(results_channel)
end

# Define analysis functions
analysis_functions = [
    (:total_mass, gas -> msum(gas, :Msol)),
    (:mean_density, gas -> mean(getvar(gas, :rho, :nH))),
    (:mass_array, gas -> getvar(gas, :mass))]

7.2 Adaptive Load Balancing

Use case: Workloads with highly variable execution times (Pseudocode).

using Mera, Base.Threads

function adaptive_analysis(data_items)
    # Use @spawn for dynamic load balancing
    tasks = []

    for item in data_items
        task = @spawn begin
            # Execution time varies greatly by data size
            if estimate_complexity(item) > COMPLEXITY_THRESHOLD
                # Use more resources for complex analysis
                complex_analysis(item; max_threads=4)
            else
                # Simple analysis needs fewer resources
                simple_analysis(item; max_threads=1)
            end
        end
        push!(tasks, task)
    end

    # Fetch all results (tasks complete in variable order)
    return fetch.(tasks)
end

<!–### 7.3 Hierarchical Parallelism

Use case: Multi-level parallel decomposition.

using Mera, Base.Threads

function hierarchical_analysis(simulation_paths)
    # Level 1: Parallel across simulations
    simulation_tasks = []

    for sim_path in simulation_paths
        sim_task = @spawn begin
            snapshots = find_snapshots(sim_path)

            # Level 2: Parallel across snapshots within simulation
            snapshot_results = Vector{Any}(undef, length(snapshots))
            @threads for (i, snap) in enumerate(snapshots)
                info = getinfo(snap, sim_path)
                gas = gethydro(info; lmax=9, max_threads=1)  # Serial at level 3

                # Level 3: Parallel across variables (controlled)
                vars = [:rho, :T, :p]
                projections = projection(gas, vars; max_threads=2)

                snapshot_results[i] = (snapshot=snap, projections=projections)
            end

            (simulation=sim_path, results=snapshot_results)
        end
        push!(simulation_tasks, sim_task)
    end

    return fetch.(simulation_tasks)
end

–>

8 Thread-Safe Programming

8.0 Quick Practice: Thread Safety Fundamentals

Understanding thread safety is crucial. Let's see the difference between safe and unsafe operations:

using Base.Threads

# ❌ UNSAFE: Race condition demonstration
function unsafe_accumulation()
    total = 0
    @threads for i in 1:1000
        total += i  # DANGER: Multiple threads writing to same variable
    end
    return total
end

# ✅ SAFE: Using atomic operations
function safe_accumulation()
    total = Atomic{Int}(0)
    @threads for i in 1:1000
        atomic_add!(total, i)  # SAFE: Atomic operation
    end
    return total[]
end

# ✅ SAFE: Pre-allocated array (each thread writes to different index)
function safe_array_approach()
    results = Vector{Int}(undef, 1000)
    @threads for i in 1:1000
        results[i] = i  # SAFE: Each thread writes to different index
    end
    return sum(results)
end

# Test all approaches
println("🧪 Thread Safety Demonstration:")
expected = sum(1:1000)  # Should be 500500

println("Expected result: ", expected)
println("Unsafe result: ", unsafe_accumulation(), " (may vary!)")
println("Safe atomic result: ", safe_accumulation())
println("Safe array result: ", safe_array_approach())

What You'll Learn: The unsafe version may give different results each time, while safe versions are consistent.

8.1 Race Conditions and Thread Safety

Race conditions occur when multiple threads access shared data simultaneously without synchronization, leading to unpredictable results:

# DANGEROUS: Race condition
total = 0.0
@threads for i in 1:1_000_000
    global total += compute_value(i)  # Multiple threads writing to same variable
end
println(total)  # Result is unpredictable!

8.2 Atomic Operations

Atomic variables provide thread-safe operations for simple data types:

using Base.Threads

# Thread-safe accumulation using atomics
total = Threads.Atomic{Float64}(0.0)
@threads for i in 1:1_000_000
    value = compute_value(i)
    atomic_add!(total, value)
end
println("Total: $(total[])")  # Reliable result

# Available atomic operations
counter = Threads.Atomic{Int}(0)
atomic_add!(counter, 5)        # Add 5
atomic_sub!(counter, 2)        # Subtract 2
old_val = atomic_xchg!(counter, 10)  # Exchange values
success = atomic_cas!(counter, 10, 20)  # Compare-and-swap

println("old_val=",old_val)
println(" counter=",counter)
println(" success=",success)

8.3 Thread-Safe Data Collection Patterns

Pattern 1: Pre-allocated Output Arrays

# Safe: Each thread writes to different indices
results = Vector{Float64}(undef, n_calculations)
@threads for i in 1:n_calculations
    results[i] = monte_carlo_step(i)  # No race condition
end

Pattern 2: Thread-Local Accumulators with Atomic Finalization

using Mera, Base.Threads

function thread_safe_stellar_histogram(particle_data)
    ages = getvar(particle_data, :age, :Myr)
    masses = getvar(particle_data, :mass, :Msol)

    # Define bin edges and atomic counters (0-50, 50-100, ..., 450-500 Myr)
    age_edges = collect(0.0:50.0:500.0)
    nbins = length(age_edges) - 1
    mass_per_bin = [Threads.Atomic{Float64}(0.0) for _ in 1:nbins]

    # Thread-safe binning: each thread atomically adds into its bin
    @threads for i in eachindex(ages)
        age = ages[i]
        mass = masses[i]

        bin_index = searchsortedfirst(age_edges, age) - 1
        if 1 <= bin_index <= nbins
            Threads.atomic_add!(mass_per_bin[bin_index], mass)
        end
    end

    # Materialize atomic results into a plain Float64 vector
    return [a[] for a in mass_per_bin]
end

8.4 Locks for Complex Data Structures

For complex shared data structures that can't use atomics:

using Base.Threads: ReentrantLock, lock

# Thread-safe access to complex data structures
lk = ReentrantLock()
shared_results = Dict{String, Vector{Float64}}()

@threads for analysis_id in analysis_ids
    result_vector = perform_complex_analysis(analysis_id)

    # Thread-safe dictionary update
    lock(lk) do
        shared_results[analysis_id] = result_vector
    end
end

9 Transforming Single-Threaded Tutorials

9.1 Tutorial Transformation Overview

9.2 Example 1: Parallel First Inspection

Transforming 01hydroFirst_Inspection.ipynb

Original (single-threaded):

using Mera

# Load and inspect one snapshot
info = getinfo(100, SIMPATH)
gas = gethydro(info; lmax=10)

println("Time: ", gettime(info, :Myr), " Myr")
println("Total mass: ", msum(gas, :Msol), " Msol")
println("Number of cells: ", length(gas.data))

Multi-threaded version:

using Mera, Base.Threads

# Inspect multiple snapshots in parallel
snapshots = 100:25:400
results = Vector{NamedTuple}(undef, length(snapshots))

@threads for (i, snapshot) in enumerate(snapshots)
    info = getinfo(snapshot, SIMPATH)
    # Use max_threads=1 to reduce contention in outer loop
    gas = gethydro(info; lmax=10, max_threads=1)

    results[i] = (
        snapshot = snapshot,
        time_myr = gettime(info, :Myr),
        total_mass = msum(gas, :Msol),
        n_cells = length(gas.data),
        mean_density = mean(getvar(gas, :rho, :nH))
    )
end

# Display results
for r in results
    println("Snapshot $(r.snapshot): $(r.time_myr) Myr, $(r.total_mass) Msol")
end

9.3 Example 2: Parallel Selections

Transforming 02hydroLoad_Selections.ipynb

Original (single-threaded):

# Load different spatial selections sequentially
info = getinfo(200, SIMPATH)

# Central region
gas_center = gethydro(info; xrange=[-5,5], yrange=[-5,5], zrange=[-2,2])
mass_center = msum(gas_center, :Msol)

# Disk region
gas_disk = gethydro(info; xrange=[-10,10], yrange=[-10,10], zrange=[-1,1])
mass_disk = msum(gas_disk, :Msol)

Multi-threaded version:

using Mera, Base.Threads

# Define multiple spatial selections
selections = [
    (name="center", xrange=[-5,5], yrange=[-5,5], zrange=[-2,2]),
    (name="disk", xrange=[-10,10], yrange=[-10,10], zrange=[-1,1]),
    (name="halo", xrange=[-25,25], yrange=[-25,25], zrange=[-10,10]),
    (name="north", xrange=[-15,15], yrange=[-15,15], zrange=[2,8])
]

results = Vector{NamedTuple}(undef, length(selections))

@threads for (i, sel) in enumerate(selections)
    info = getinfo(200, SIMPATH)
    # Extract selection parameters (excluding name)
    selection_kwargs = [(k,v) for (k,v) in pairs(sel) if k != :name]

    gas = gethydro(info; lmax=10, max_threads=1, selection_kwargs...)

    results[i] = (
        region = sel.name,
        mass = msum(gas, :Msol),
        volume = (sel.xrange[2]-sel.xrange[1]) *
                (sel.yrange[2]-sel.yrange[1]) *
                (sel.zrange[2]-sel.zrange[1]),
        mean_density = mean(getvar(gas, :rho, :nH))
    )
end

# Compare regions
for r in results
    density_msol_pc3 = r.mass / r.volume * (1000/3.086e18)^3
    println("$(r.region): $(r.mass) Msol, density $(density_msol_pc3) Msol/pc³")
end

9.4 Example 3: Parallel Projections

Transforming 06hydroProjection.ipynb

Original (single-threaded):

# Create projections one by one
info = getinfo(300, SIMPATH)
gas = gethydro(info; lmax=11)

# Sequential projections
rho_map = projection(gas, :rho; direction=:z, lmax=9)
temp_map = projection(gas, :T; direction=:z, lmax=9)
vel_map = projection(gas, :vz; direction=:z, lmax=9)

Multi-threaded version:

using Mera

info = getinfo(300, SIMPATH)
gas = gethydro(info; lmax=11)  # Full parallelization for loading

# Create all projections at once - one thread per variable
variables = [:rho, :T, :vz, :p]
projections = projection(gas, variables; direction=:z, lmax=9)

# Access individual projections
# If you pass a single variable, projection(gas, :rho; ...) returns the map directly.
# For multiple variables, access by key if projections is keyed by variable, e.g.:
# rho_map = projections[:rho]

# Alternative: Use @spawn for more control
tasks = [Threads.@spawn projection(gas, var; direction=:z, lmax=9, max_threads=2)
         for var in variables]
projection_results = fetch.(tasks)

9.5 Example 4: Parallel VTK Export

Transforming 08hydroVTK_export.ipynb

Original (single-threaded):

# Export one snapshot to VTK
info = getinfo(250, SIMPATH)
gas = gethydro(info; lmax=10)

export_vtk(gas, "hydro_snapshot_250";
          scalars=[:rho, :p, :T],
          scalars_unit=[:nH, :K, :K])

Multi-threaded version:

using Mera, Base.Threads

# Export multiple snapshots in parallel
snapshots = 200:50:400
export_dir = "./vtk_exports"
mkpath(export_dir)  # Create directory

@threads for snapshot in snapshots
    try
        info = getinfo(snapshot, SIMPATH)
        # Load with reduced internal threading
        gas = gethydro(info; lmax=10, max_threads=2)

        # Create timestamped filename
        time_myr = gettime(info, :Myr)
        filename = joinpath(export_dir, "hydro_$(snapshot)_t$(time_myr)Myr")

        # VTK export
        export_vtk(gas, filename;
                  scalars=[:rho, :p, :T],
                  scalars_unit=[:nH, :K, :K],
                  vector=[:vx, :vy, :vz],
                  vector_unit=:km_s)

        println("Exported snapshot $snapshot")

    catch e
        @error "Failed to export snapshot $snapshot: $e"
    end
end

println("VTK export completed for $(length(snapshots)) snapshots")

10 Benchmarking & Performance Tuning

10.1 Finding Optimal max_threads Values

Different functions have different optimal thread counts. Benchmark systematically:

using Mera, BenchmarkTools

function benchmark_gethydro(info)
    println("Benchmarking gethydro with different max_threads:")
    for t in (1, 2, 4, 8, Threads.nthreads())
        # Use @belapsed for single measurement (more reliable than @btime here)
        time = @belapsed gethydro($info; lmax=12, max_threads=$t)
        println("  max_threads=$t → $(round(time, digits=3)) seconds")
    end
end

function benchmark_projection(gas)
    println("Benchmarking projection with different max_threads:")
    vars = [:rho, :T, :vx, :vy]  # 4 variables

    for t in (1, 2, 4, 8, min(8, Threads.nthreads()))
        time = @belapsed projection($gas, $vars; lmax=10, max_threads=$t)
        println("  max_threads=$t → $(round(time, digits=3)) seconds")
    end
end

function benchmark_export_vtk(gas, temp_prefix)
    println("Benchmarking export_vtk (note: export_vtk uses internal threading automatically):")

    filename = "$(temp_prefix)_test"
    time = @belapsed begin
        export_vtk($gas, $filename; scalars=[:rho])
        # Clean up
        rm("$(filename).vti", force=true)
    end
    println("  export_vtk time → $(round(time, digits=3)) seconds")
end

# Run benchmarks
info = getinfo(300, SIMPATH)
gas = gethydro(info; lmax=10, max_threads=1)  # Load once for projection tests

benchmark_gethydro(info)
benchmark_projection(gas)
benchmark_export_vtk(gas, "./benchmark_temp")

Example Output:

Benchmarking gethydro with different max_threads:
  max_threads=1 → 3.245 seconds
  max_threads=2 → 1.823 seconds
  max_threads=4 → 1.156 seconds
  max_threads=8 → 1.089 seconds
  max_threads=16 → 1.092 seconds

Benchmarking projection with different max_threads:
  max_threads=1 → 2.134 seconds
  max_threads=2 → 1.087 seconds
  max_threads=4 → 0.589 seconds  ← Sweet spot
  max_threads=8 → 0.591 seconds

10.2 Memory Usage Monitoring

Monitor memory allocation and GC performance:

function monitor_memory_usage(analysis_function, data)
    println("Memory usage analysis:")

    # Clear previous allocations
    GC.gc()

    # Run analysis with detailed timing
    t = @timed analysis_function(data)

    allocated_mb = t.bytes / 1024^2
    gc_time_ms = t.gctime * 1000

    println("  Total allocated: $(round(allocated_mb, digits=1)) MB")
    println("  GC time: $(round(gc_time_ms, digits=1)) ms")

    if gc_time_ms > 500  # More than 0.5s in GC
        println("  ⚠️  High GC time detected. Consider:")
        println("     - Increasing --gcthreads")
        println("     - Pre-allocating arrays")
        println("     - Using in-place operations")
        println("     - Processing data in smaller chunks")
    end

    return t.value
end

# Example usage
function test_analysis(snapshots)
    @threads for s in snapshots
        info = getinfo(s, SIMPATH)
        gas = gethydro(info; lmax=10, max_threads=1)
        msum(gas, :Msol)
    end
end

result = monitor_memory_usage(test_analysis, 100:10:150)

10.3 Thread Utilization Analysis

Check if threads are being used efficiently:

using Statistics

function analyze_thread_utilization(workload_function, args...; tasks=Threads.nthreads())
    # Track work distribution across threads
    work_counters = [Threads.Atomic{Int}(0) for _ in 1:Threads.nthreads()]

    # Modified workload that tracks thread usage
    function tracked_workload()
        tid = Threads.threadid()
        Threads.atomic_add!(work_counters[tid], 1)
        return workload_function(args...)
    end

    # Run the workload across tasks
    start_time = time()
    @threads for _ in 1:tasks
        tracked_workload()
    end
    end_time = time()

    # Analyze utilization
    work_counts = [counter[] for counter in work_counters]
    total_work = sum(work_counts)

    println("Thread utilization analysis:")
    println("  Total execution time: $(round(end_time - start_time, digits=2))s")
    println("  Total work units: $total_work")

    for (i, count) in enumerate(work_counts)
        if count > 0
            percentage = round(count / total_work * 100, digits=1)
            println("  Thread $i: $count tasks ($(percentage)%)")
        end
    end

    # Load balance coefficient of variation (lower is better)
    active_threads = sum(work_counts .> 0)
    if active_threads > 1
        cv = std(work_counts) / mean(work_counts)
        println("  Load balance CV: $(round(cv, digits=3)) (lower is better)")

        if cv > 0.5
            println("  ⚠️  Poor load balance detected. Consider:")
            println("     - Using @spawn instead of @threads for variable workloads")
            println("     - Reducing task granularity")
        end
    end

    return nothing
end

11 Best Practices & Troubleshooting

11.1 Threading Best Practices

1. Choose One Level of Parallelism

# GOOD: Outer loop parallelism
@threads for snapshot in snapshots
    gas = gethydro(info; max_threads=1)  # Inner serial
end

# GOOD: Inner parallelism
gas = gethydro(info)  # Full threads
projections = projection(gas, variables)  # One thread per variable

# AVOID: Uncontrolled nesting
@threads for snapshot in snapshots
    gas = gethydro(info)  # Full threads
    projection(gas, variables)  # More full threads = contention and slowdowns
end

2. Cap Threads Appropriately

# Rule of thumb for max_threads:
# - I/O bound: Higher thread counts (4-8)
# - CPU bound: Match physical cores
# - Memory bound: Lower thread counts (2-4)

export_vtk(gas, filename)                       # Uses internal threading automatically
projection(gas, vars; max_threads=4)            # CPU bound, moderate threads
gethydro(info; max_threads=2)                   # Memory bound, fewer threads

3. Monitor and Profile

# Always check GC overhead
@time result = your_analysis_function()
# Look for "% gc time" - keep it under 15%

# Use BenchmarkTools for reliable measurements
@benchmark your_function($args)

# Profile allocation hotspots
using Profile
@profile your_function(args)
Profile.print()

4. Handle Errors Gracefully

@threads for item in workload
    try
        process_item(item)
    catch e
        @error "Failed to process $item: $e"
    end
end

11.2 Common Issues and Solutions

Issue 1: Poor Scaling Performance

Symptom: Adding more threads doesn't improve (or worsens) performance

Causes and Solutions:

• Memory bandwidth bottleneck: Reduce threads to match memory channels (typically 4-8)
• False sharing: Use padding or redesign data structures
• Over-synchronization: Minimize shared state, use thread-local storage
• I/O contention: For network storage, fewer threads may be better

Issue 2: High GC Time

Symptom: @time shows >20% gc time

Solutions:

# Increase GC threads
# julia --gcthreads=8

# Pre-allocate arrays
results = Vector{Float64}(undef, n)  # Instead of growing with push!

# Use in-place operations
@. array1 += array2  # Instead of array1 = array1 + array2

# Process in chunks
for chunk in data_chunks
    process(chunk)
    GC.gc()  # Force cleanup between chunks
end

Issue 3: Crashes or Incorrect Results

Symptom: Program crashes, hangs, or produces wrong answers

Causes and Solutions:

• Race conditions: Use atomics or locks for shared data
• Unsafe library usage: Many C libraries aren't thread-safe
• Stack overflow: Large recursion depths on multiple threads

11.3 Advanced Debugging with verbose_threads

Mera provides powerful built-in debugging capabilities through the verbose_threads parameter.

Enable Threading Diagnostics

# Enable detailed threading diagnostics for projections
proj = projection(gas, [:rho, :T, :vx, :vy];
                 verbose_threads=true,
                 max_threads=4,
                 verbose=true)

What verbose_threads=true Shows You:

🧵 THREADING DIAGNOSTICS:
====================================
Thread assignment:
  Variable :rho → Thread 1
  Variable :T   → Thread 2
  Variable :vx  → Thread 3
  Variable :vy  → Thread 4

Load balancing:
  Thread 1: 2.341s (28.5% of total time)
  Thread 2: 2.287s (27.8% of total time)  ← Well balanced
  Thread 3: 2.398s (29.2% of total time)
  Thread 4: 2.195s (26.7% of total time)

Memory allocation per thread:
  Thread 1: 245.7 MB allocated
  Thread 2: 243.1 MB allocated
  Thread 3: 251.2 MB allocated
  Thread 4: 238.9 MB allocated

Performance metrics:
  Total parallel time: 2.398s (max thread time)
  Sequential estimate: 9.221s (sum of thread times)
  Parallel efficiency: 96.2% (excellent)
  Load balance score: 0.94 (0.8+ is good)

Interpreting Threading Diagnostics:

1. Load Balance Score:

   • 0.9+ = Excellent load balancing
   • 0.8-0.9 = Good load balancing
   • <0.8 = Poor load balancing, consider fewer threads

2. Parallel Efficiency:

   • 90%+ = Great threading benefit
   • 70-90% = Reasonable threading benefit
   • <70% = Threading overhead too high, reduce threads

3. Memory Allocation Patterns:

   • Similar allocation across threads = good
   • One thread allocating much more = potential bottleneck

Debugging Threading Performance Issues

using Mera

# Load test data
info = getinfo(400, SIMPATH)
gas = gethydro(info; lmax=10)

# Test 1: Check if threading helps
println("=== SINGLE THREAD TEST ===")
@time proj_serial = projection(gas, [:rho, :T];
                               max_threads=1,
                               verbose_threads=true)

println("\n=== MULTI THREAD TEST ===")
@time proj_parallel = projection(gas, [:rho, :T];
                                 max_threads=4,
                                 verbose_threads=true)

# Compare the diagnostics to identify bottlenecks

Common Issues Diagnosed by verbose_threads:

1. Poor Load Balancing:

Thread 1: 1.234s (45% of time)  ← Overloaded
Thread 2: 0.892s (32% of time)
Thread 3: 0.634s (23% of time)  ← Underutilized

Fix: Use fewer threads or different data partitioning

1. Memory Contention:

Thread 1: 145.7 MB allocated
Thread 2: 2891.3 MB allocated  ← Memory hog
Thread 3: 151.2 MB allocated

Fix: Reduce threads or check for memory leaks in specific variables

1. Resource Starvation:

Total parallel time: 4.521s
Sequential estimate: 3.987s  ← Parallel slower than serial!
Parallel efficiency: 88.2%

Fix: Use max_threads=1 or investigate I/O bottlenecks

Advanced Debugging Tools

Thread-Safe Debug Output:

using Base.Threads: SpinLock

debug_lock = SpinLock()
function thread_safe_debug(msg)
    lock(debug_lock) do
        timestamp = round(time(), digits=3)
        println("[$timestamp] Thread $(threadid()): $msg")
    end
end

# Use in threaded code
@threads for i in 1:10
    thread_safe_debug("Starting work on item $i")
    # ... work ...
    thread_safe_debug("Completed item $i")
end

Performance Profiling with Threading:

using Profile

# Profile threaded code
@profile begin
    @threads for i in 1:8
        info = getinfo(i*50 + 100, SIMPATH)
        gas = gethydro(info; lmax=9, max_threads=1)
        proj = projection(gas, :rho; max_threads=2, verbose_threads=true)
    end
end

# View profile results
Profile.print()
# Look for thread contention, memory allocation hotspots

Memory Leak Detection:

function detect_memory_growth(test_function, n_iterations=10)
    println("Memory growth analysis:")

    initial_memory = Base.gc_live_bytes()
    println("Initial memory: $(round(initial_memory/1024^2, digits=2)) MB")

    for i in 1:n_iterations
        test_function()
        GC.gc()  # Force cleanup
        current_memory = Base.gc_live_bytes()
        growth = (current_memory - initial_memory) / 1024^2

        println("Iteration $i: $(round(growth, digits=2)) MB growth")

        if growth > 100  # More than 100MB growth
            @warn "Potential memory leak detected at iteration $i"
        end
    end
end

# Test for memory leaks in threaded code
test_func() = begin
    @threads for i in 1:4
        gas = gethydro(getinfo(100+i, SIMPATH); lmax=8, max_threads=1)
        projection(gas, :rho; verbose_threads=true)
    end
end

detect_memory_growth(test_func)

Race Condition Detection:

function test_for_race_conditions(test_function, n_trials=100)
    println("Testing for race conditions over $n_trials trials...")

    # Get reference result (serial)
    reference_result = test_function()

    # Test multiple times
    failures = 0
    for trial in 1:n_trials
        result = test_function()
        if result != reference_result
            failures += 1
            println("⚠️ Race condition detected in trial $trial!")
            println("Expected: $reference_result")
            println("Got: $result")
        end

        if trial % 20 == 0
            println("Completed $trial/$n_trials trials, $failures failures")
        end
    end

    if failures == 0
        println("✅ No race conditions detected over $n_trials trials")
    else
        println("❌ Race conditions detected in $failures/$n_trials trials")
    end
end

Threading Environment Diagnostics:

function diagnose_threading_environment()
    println("🔍 THREADING ENVIRONMENT DIAGNOSIS")
    println("="^50)

    # Basic thread info
    println("Available threads: $(Threads.nthreads())")
    println("CPU cores: $(Sys.CPU_THREADS)")

    # HPC cluster warning
    if Sys.CPU_THREADS > 16 && Threads.nthreads() == Sys.CPU_THREADS
        println("⚠️  You're using all $(Sys.CPU_THREADS) cores - appropriate for personal systems only!")
        println("   On HPC clusters, use explicit thread counts to avoid oversubscription")
    end

    # Check for Julia version threading features
    println("Julia version: $(VERSION)")
    if VERSION >= v"1.9"
        println("✅ Composable threading supported")
    else
        println("⚠️ Consider upgrading Julia for better threading")
    end

    # Test basic threading
    println("\n🧪 Basic threading test:")
    thread_times = Vector{Float64}(undef, Threads.nthreads())
    @threads for i in 1:Threads.nthreads()
        start_time = time()
        sleep(0.1)  # Simulate work
        thread_times[i] = time() - start_time
    end

    for (i, t) in enumerate(thread_times)
        println("Thread $i: $(round(t*1000, digits=1))ms")
    end

    # Check for thread starvation
    if maximum(thread_times) - minimum(thread_times) > 0.05
        println("⚠️ Potential thread scheduling issues detected")
    else
        println("✅ Threading appears to work correctly")
    end
end

# Run diagnosis
diagnose_threading_environment()

12 Complete Working Examples

12.1 Multi-Simulation Analysis Pipeline

using Mera, Base.Threads
using Statistics, Printf

function comprehensive_analysis_pipeline(simulation_paths)
    """
    Complete pipeline: load simulations, analyze multiple snapshots,
    create projections, and export results with full threading control.
    """

    all_results = Vector{Any}(undef, length(simulation_paths))

    # Outer level: Parallel across simulations
    @threads for (j, sim_path) in enumerate(simulation_paths)
        println("Analyzing simulation: $sim_path")

        try
            # Find available snapshots
            snapshots = find_snapshots_in_path(sim_path)  # Custom function
            sim_results = []

            # Process snapshots in this simulation
            for snapshot in snapshots
                info = getinfo(snapshot, sim_path)
                time_myr = gettime(info, :Myr)

                # Load data with controlled threading
                gas = gethydro(info; lmax=10, max_threads=2)
                particles = getparticles(info; max_threads=2)

                # Parallel projections - one thread per variable
                gas_variables = [:rho, :T, :p]
                gas_projections = projection(gas, gas_variables;
                                           direction=:z, lmax=9, max_threads=3)

                # Particle projection
                particle_proj = projection(particles, :mass;
                                         direction=:z, max_threads=1)

                # Analysis calculations
                gas_mass = msum(gas, :Msol)
                stellar_mass = msum(particles, :Msol)
                mean_density = mean(getvar(gas, :rho, :nH))
                mean_temp = mean(getvar(gas, :T, :K))

                # Store results
                push!(sim_results, (
                    snapshot = snapshot,
                    time_myr = time_myr,
                    gas_mass = gas_mass,
                    stellar_mass = stellar_mass,
                    mean_density = mean_density,
                    mean_temperature = mean_temp,
                    gas_projections = gas_projections,
                    particle_projection = particle_proj
                ))
            end

            # Write to preallocated slot (thread-safe)
            all_results[j] = (simulation=sim_path, snapshots=sim_results)

        catch e
            @error "Failed to analyze simulation $sim_path: $e"
        end
    end

    return all_results
end

function find_snapshots_in_path(path)
    # Placeholder - implement based on your file structure
    return 100:50:500
end

# Usage
simulation_paths = ["/data/sim_001", "/data/sim_002", "/data/sim_003"]
results = comprehensive_analysis_pipeline(simulation_paths)

# Process results
for sim_result in results
    println("Simulation: $(sim_result.simulation)")
    for snap_result in sim_result.snapshots
        @printf("  t=%.1f Myr: Gas=%.2e Msol, Stars=%.2e Msol, T̄=%.1f K\n",
                snap_result.time_myr, snap_result.gas_mass,
                snap_result.stellar_mass, snap_result.mean_temperature)
    end
end

12.2 Parameter Study with Threading

using Mera, Base.Threads

function parallel_parameter_study()
    """
    Run analysis across multiple parameter combinations in parallel
    """

    # Define parameter grid
    lmax_values = [8, 9, 10, 11]
    center_positions = [[24, 24, 24], [25, 25, 25], [23, 23, 23]]
    box_sizes = [5, 10, 15]  # kpc

    # Create all parameter combinations
    param_combinations = [(lmax=l, center=c, size=s)
                         for l in lmax_values
                         for c in center_positions
                         for s in box_sizes]

    results = Vector{NamedTuple}(undef, length(param_combinations))

    # Process parameter combinations in parallel
    @threads for (i, params) in enumerate(param_combinations)
        try
            info = getinfo(300, SIMPATH)

            # Load data with parameter-specific settings
            gas = gethydro(info;
                          lmax = params.lmax,
                          center = params.center,
                          xrange = [-params.size, params.size],
                          yrange = [-params.size, params.size],
                          zrange = [-params.size, params.size],
                          range_unit = :kpc,
                          max_threads = 1)  # Serial inside threaded loop

            # Perform analysis
            total_mass = msum(gas, :Msol)
            mean_density = mean(getvar(gas, :rho, :nH))
            n_cells = length(gas.data)

            # Create projection
            density_proj = projection(gas, :rho; direction=:z,
                                    lmax=params.lmax-1, max_threads=2)

            # Store results
            results[i] = (
                parameters = params,
                total_mass = total_mass,
                mean_density = mean_density,
                n_cells = n_cells,
                projection = density_proj,
                success = true
            )

        catch e
            @error "Parameter combination $params failed: $e"
            results[i] = (parameters=params, success=false, error=e)
        end
    end

    # Filter successful results and analyze
    successful_results = filter(r -> r.success, results)

    println("Parameter study completed:")
    println("  Total combinations: $(length(param_combinations))")
    println("  Successful: $(length(successful_results))")

    # Find optimal parameters (example: maximize resolved cells)
    best_result = findmax(r -> r.n_cells, successful_results)[2]

    println("Best parameters (most cells resolved):")
    println("  lmax: $(successful_results[best_result].parameters.lmax)")
    println("  center: $(successful_results[best_result].parameters.center)")
    println("  size: $(successful_results[best_result].parameters.size) kpc")
    println("  cells: $(successful_results[best_result].n_cells)")

    return successful_results
end

# Run parameter study
study_results = parallel_parameter_study()

12.3 Time Series Analysis with Memory Management

using Mera, Base.Threads
using Statistics

function memory_efficient_time_series(snapshot_range, chunk_size=5)
    """
    Process time series in chunks to manage memory usage
    """

    # Pre-allocate result arrays
    n_snapshots = length(snapshot_range)
    times = Vector{Float64}(undef, n_snapshots)
    gas_masses = Vector{Float64}(undef, n_snapshots)
    stellar_masses = Vector{Float64}(undef, n_snapshots)
    mean_densities = Vector{Float64}(undef, n_snapshots)
    mean_temperatures = Vector{Float64}(undef, n_snapshots)

    # Process in chunks to manage memory
    for chunk_start in 1:chunk_size:n_snapshots
        chunk_end = min(chunk_start + chunk_size - 1, n_snapshots)
        chunk_indices = chunk_start:chunk_end

        println("Processing chunk $(chunk_start):$(chunk_end)")

        # Process chunk in parallel
        @threads for i in chunk_indices
            snapshot = snapshot_range[i]

            try
                info = getinfo(snapshot, SIMPATH)

                # Load data with memory-conscious settings
                gas = gethydro(info; lmax=10, max_threads=1)
                particles = getparticles(info; max_threads=1)

                # Extract variables efficiently
                gas_rho = getvar(gas, :rho, :nH)
                gas_temp = getvar(gas, :T, :K)
                gas_mass_vals = getvar(gas, :mass, :Msol)
                particle_masses = getvar(particles, :mass, :Msol)

                # Compute and store results
                times[i] = gettime(info, :Myr)
                gas_masses[i] = sum(gas_mass_vals)
                stellar_masses[i] = sum(particle_masses)
                mean_densities[i] = mean(gas_rho)
                mean_temperatures[i] = mean(gas_temp)

            catch e
                @error "Failed to process snapshot $snapshot: $e"
                # Fill with NaN for failed snapshots
                times[i] = NaN
                gas_masses[i] = NaN
                stellar_masses[i] = NaN
                mean_densities[i] = NaN
                mean_temperatures[i] = NaN
            end
        end

        # Force garbage collection between chunks
        GC.gc()
        println("Chunk completed, memory freed")
    end

    # Filter out failed snapshots
    valid_indices = .!isnan.(times)

    return (
        times = times[valid_indices],
        gas_masses = gas_masses[valid_indices],
        stellar_masses = stellar_masses[valid_indices],
        mean_densities = mean_densities[valid_indices],
        mean_temperatures = mean_temperatures[valid_indices],
        n_successful = sum(valid_indices),
        n_failed = sum(.!valid_indices)
    )
end

# Run time series analysis
results = memory_efficient_time_series(100:10:500, 10)  # Process 10 snapshots at a time

println("Time series analysis completed:")
println("  Successful snapshots: $(results.n_successful)")
println("  Failed snapshots: $(results.n_failed)")
println("  Time range: $(minimum(results.times)) - $(maximum(results.times)) Myr")
println("  Gas mass range: $(minimum(results.gas_masses)) - $(maximum(results.gas_masses)) Msol")

12.4 Time Series from Single-File JLD2 “Mera Files”

using Base.Threads, Mera
using Statistics

"""
Analyze a time series of single-file JLD2 outputs ("Mera files") using Mera.loaddata.

Assumptions:
- Files are named like: output_XXXXX.jld2 (standard Mera format)
- Data type is one of :hydro, :particles, :gravity, :clumps

Arguments:
- dir::AbstractString: directory with output_*.jld2 files
- datatype::Symbol: which dataset to load from each file (default :hydro)

Returns NamedTuple with vectors for outputs, files, times (Myr), total_mass, mean_density.
"""
function analyze_merafiles_timeseries(dir::AbstractString; datatype::Symbol=:hydro)
    # Discover files and parse output numbers
    allfiles = readdir(dir; join=true)
    merafiles = filter(f -> endswith(lowercase(f), ".jld2") && occursin(r"output_\d+\.jld2$", lowercase(basename(f))), allfiles)
    if isempty(merafiles)
        error("No Mera .jld2 files (output_XXXXX.jld2) found in: $dir")
    end

    outputs = map(merafiles) do f
        m = match(r"output_(\d+)\.jld2$", basename(f))
        isnothing(m) && error("Unrecognized filename: $(basename(f))")
        parse(Int, m.captures[1])
    end

    # Sort by output number
    p = sortperm(outputs)
    outputs = outputs[p]
    files = merafiles[p]
    n = length(files)

    # Preallocate results
    times = fill(Float64(NaN), n)
    total_mass = Vector{Float64}(undef, n)
    mean_density = Vector{Float64}(undef, n)

    # Threaded outer loop; internal routines manage their own threading
    @threads for i in 1:n
        out = outputs[i]
        # Load the requested dataset from the Mera file directory
        data_obj = loaddata(out, dir, datatype)

        # Get time directly from the data object (Myr)
        times[i] = gettime(data_obj, :Myr)

        # Compute metrics (adapt as needed for non-hydro datatypes)
        total_mass[i] = msum(data_obj, :Msol)
        mean_density[i] = try
            mean(getvar(data_obj, :rho, :nH))
        catch
            NaN
        end
    end

    return (outputs=outputs, files=files, times=times, total_mass=total_mass, mean_density=mean_density)
end

# Example usage
dir = "/path/to/your/merafiles"  # update this
res = analyze_merafiles_timeseries(dir; datatype=:hydro)

println("Analyzed $(length(res.files)) Mera JLD2 files")
finite_times = filter(isfinite, res.times)
println("Time range (Myr): ", isempty(finite_times) ? (NaN, NaN) : (minimum(finite_times), maximum(finite_times)))
println("Mass range (Msol): ", (minimum(res.total_mass), maximum(res.total_mass)))
println("Mean density range (nH): ", (minimum(res.mean_density), maximum(res.mean_density)))

Notes:

• Uses Mera.loaddata(output, dir, datatype) to read canonical “Mera files.”
• Adjust metrics for non-hydro data (e.g., particles don’t have :rho).
• Tune parallelism by batching outputs if your storage is slow; see Section 3 on I/O contention.

Summary

This comprehensive guide provides everything needed to harness Julia's multi-threading capabilities with Mera:

Key Takeaways:

1. Understand resource contention and use max_threads to control it
2. Choose your parallelization level - outer loops or inner kernels, not both uncontrolled
3. Benchmark systematically to find optimal thread counts for your hardware
4. Monitor GC performance and tune for large dataset processing
5. Transform existing tutorials with minimal code changes for immediate benefits

Threading Patterns:

• Outer-loop: Multiple snapshots/parameters → @threads + max_threads=1 inner
• Inner-kernel: Single large dataset → full internal threading in Mera calls
• Mixed: Controlled combination with explicit thread budgets

Best Practices:

• Start Julia with balanced thread pools: julia --threads=auto --gcthreads=auto (uses all available CPU cores)
• Use atomic operations for thread-safe data collection
• Avoid false sharing with proper data structure design
• Profile and benchmark before optimizing

By following these patterns, you can transform single-threaded analysis scripts into high-throughput, scalable workflows that fully utilize modern multi-core processors—all within pure Julia code, no external dependencies required.
